Product Description
rainproof switching power supplies
1.factory direct sale
2.tiny ripple
3.ce rohs approved
1.factory direct sale
2.tiny ripple
3.ce rohs approved
CE RoHS approved IP65 150W 12V 12.5A rainproof switching power supplies
Note: input voltage:85~264vac
output voltage:5v 12v 15v 24v 27v 48v
a.We do have enough ability to produce your customized order as long as you tell us your demand.
b.Samples are available
c.High quality and competitive price .
d.If need samples, Kindly contact us
e.2 years warranty
b.Samples are available
c.High quality and competitive price .
d.If need samples, Kindly contact us
e.2 years warranty
1.universal AC input
2.Protections: short circuit, over load, over temp,
3.Build-in EMI filter with tiny ripple
4.100%full load burn-in test
5.Small volume high-efficiency
6.Conform to EN60950 GB4943 UL60950 safety standards
7.Conform to GB9254, EN55022,EMC standards
| AC input voltage range | 85~264VAC/170~264VAC |
| Input current | 3.2A/110V, 1.6A/230V |
| Input frequency | 47~63Hz |
| Inrush current | cold start, 20A/115V,40A/230V |
| Input leakage current | < 3mA/240VAC |
| Output voltage adjust range | ±10%rated output voltage |
| Output overload protection | 105-~150%, hiccup mode, auto recovery |
| Output over voltage protection | |
| Withstand voltage | I/P-O/P: 1.5KVAC/1min, I/P-F/G: 1.5KVAC/1min, O/P-F/G: 0.5KVAC/1min |
| Operating temperature | -20°C ~+60°C |
| Operating humidity | 20%~90% |
| packing | 20pcs/13.6kg |
| size | 245*92*52.5mm |
| weight | 0.68kg/pcs |
led driver switching power supply 150w main products
| model | outpot voltage |
output
current
| rated power | error | efficiency |
| FX150-W1V5 | 5V | 0~30A | 150W | ± 1% | 81% |
| FX150-W1V12 | 12V | 0~12.5A | 150W | ± 1% | 84% |
| FX150-W1V15 | 15V | 0~10A | 150W | ± 1% | 84% |
| FX150-W1V24 | 24V | 0~6.5A | 150W | ± 1% | 85% |
| FX150-W1V27 | 27V | 0~5.6A | 150W | ± 1% | 86% |
| FX150-W1V48 | 48V | 0~3.2A | 150W | ± 1% | 87% |
