250W Waterproof 24VDC Power Supply
100% full load burn-in test
Two years warranty
CE and ROHS approved
Long lifespan
100% full load burn-in test
Two years warranty
CE and ROHS approved
Long lifespan
250w waterproof 24vdc power supply
Our variable power supplies are widely used in led strip, nixie tube, street light, lamp and light, hotel, hospital and house decoration. FX waterproof type is our hot-selling type. OEM and ODM are also accepted. Welcome your trail order!
Led Driver Switching Power Supply 250w_Features
1.short circuit/ over load/ over voltage/ over temp
2. Conform to EN60950 GB4943 UL60950 Safety standards
3. Conform to CB9254 EN55022 EMC Standards
4. High quality with competitive price
5. Suitable for any where in the world
6. Built-in EMI filter with tiny ripple
7. Two years warranty
8. Life span: 50,000H
Led Driver Switching Power Supply 250w_Parameters
AC input voltage range
|
85~132VAC 170~264VAC 47~63Hz
| ||||
Input current
|
4.5A/115V 2.5A/230V
| ||||
AC inrush current
|
Cold-start current 25A/115V 50A/230V
| ||||
Leakage current
|
<3.5MA/240VAC
| ||||
DC adjustable range
|
±10% rated output voltage
| ||||
Over load protection
|
105~135% hiccup mode, auto-recovery
| ||||
Over-voltage protection
|
115~135% cut off the output, auto-recovery
| ||||
Over-temp protection
|
Rectifier≥105°C cut off the output, auto-recovery
| ||||
Setup, rise, hold up time
|
200ms, 100ms, 20ms
| ||||
Withstand voltage
|
I/P- O/P: 1.5KVAC 1 minute
I/P- FG: 1.5KVAC 1 minute
O/P- FG: 0.5KVAC 1minute
| ||||
Working temperature
|
-20 °C ~+60°C, 20%~90%RH
| ||||
Weight/ packing/ size
|
0.72Kg, 20pcs/14.5Kg, 245*92*52.5(mm)
| ||||
Model
|
Output
|
Error
|
Range
|
Efficiency
| |
FX 200- H1V5
|
5V
|
0~40A
|
± 2%
|
120mv
|
81%
|
FX 200- H1V12
|
12V
|
0~16.5A
|
± 1%
|
150mv
|
84%
|
FX 200- H1V15
|
15V
|
0~13A
|
± 1%
|
150mv
|
84%
|
FX 200-H1V24
|
24V
|
0~8.3A
|
± 1%
|
150mv
|
85%
|
FX 200-H1V27
|
27V
|
0~7.4A
|
± 1%
|
150mv
|
85%
|
FX 200-H1V48
|
48V
|
0~4.2A
|
± 1%
|
200mv
|
86%
|
